No. |
Square
Drive
(inches) |
Size
LxWxH
(mm) |
Torque / Angle
Accuracy |
Max
Operation
Range |
Measured Torque / Angle
Range |
Resolution |
PC
Connectivity |
|
AD2-030 |
CN |
1/ |
85x85x60 |
Torque Accuracy
CW: +/-3%
CCW: +/-4%
Angle Accuracy
+/- 2° ( rotating 90° at speed of 30°/sec)
(only self system accuracy) |
30 N-m
22.12 ft-lb
265.5 in-lb
306.1 kg-cm
999° |
1.5~30 N-m
1.11~22.12 ft-lb
13.3~265.5 in-lb
15.3~306.1 kg-cm
1°~360° |
0.01 N-m
0.01 ft-lb
0.1 in-lb
0.1 kg-cm
1° |
No |
|
CU |
Yes |
|
AD3-135 |
CN |
3/8 |
85x85x75 |
135 N-m
99.5 ft-lb
1195 in-lb
1378 kg-cm
999° |
6.8~135 N-m
5~99.5 ft-lb
60~1195 in-lb
69~1378 kg-cm
1°~360° |
0.1 N-m
0.1 ft-lb
1 in-lb
1 kg-cm
1° |
No |
|
CU |
Yes |
|
AD4-135 |
CN |
1/2 |
85x85x80 |
135 N-m
99.5 ft-lb
1195 in-lb
1378 kg-cm
999° |
6.8~135 N-m
5~99.5 ft-lb
60~1195 in-lb
69~1378 kg-cm
1°~360° |
0.1 N-m
0.1 ft-lb
1 in-lb
1 kg-cm
1° |
No |
|
CU |
Yes |
|
AD4-200 |
CN |
1/2 |
85x85x80 |
200 N-m
147.5ft-lb
1770 in-lb
2041 kg-cm
999° |
10~200 N-m
7.4~147.5 ft-lb
88~1770 in-lb
102~2041 kg-cm
1°~360° |
0.1 N-m
0.1 ft-lb
1 in-lb
1 kg-cm
1° |
No |
|
CU |
Yes |
|
AD4-340 |
CN |
1/2 |
85x85x80 |
340 N-m
250.7 ft-lb
3009 in-lb
3469 kg-cm
999° |
17~340 N-m
12.5~250.7 ft-lb
150~3009 in-lb
173~3469 kg-cm
1°~360° |
0.1 N-m
0.1 ft-lb
1 in-lb
1 kg-cm
1° |
No |
|
CU |
Yes |
