Model No. |
Square
Drive
(inch) |
Length
(mm) |
Accuracy |
Max
Operation
Range |
Measured Torque
Range |
Resolution |
PC
Connectivity |
|
DP2-006 |
CN |
1/4 |
216 |
CW: +/-3%
CCW:+/-4%
(only self system accuracy) |
6 N-m
4.424 ft-lb
53.09 in-lb
61.22kg-cm |
0.3~6 N-m
0.221~4.424 ft-lb
2.65~53.09 in-lb
3.06~61.22 kg-cm |
0.001 N-m
0.001 ft-lb
0.01 in-lb
0.01 kg-cm |
No |
|
CU |
Yes |
|
DP2-012 |
CN |
1/4 |
216 |
12 N-m
8.85 ft-lb
106.2 in-lb
122.4kg-cm |
0.6~12 N-m
0.44~8.85 ft-lb
5.3~106.2 in-lb
6.1~122.4 kg-cm |
0.01 N-m
0.01 ft-lb
0.1 in-lb
0.1 kg-cm |
No |
|
CU |
Yes |
|
DP2-020 |
CN |
1/4 |
216 |
20 N-m
14.75 ft-lb
177.0 in-lb
204.1kg-cm |
1~20N-m
0.74~14.75ft-lb
8.8~177.0 in-lb
10.2~204.1kg-cm |
0.01 N-m
0.01 ft-lb
0.1 in-lb
0.1 kg-cm |
No |
|
CU |
Yes |
|
DP2-030 |
CN |
1/4 |
216 |
30 N-m
22.12 ft-lb
265.5 in-lb
306.1kg-cm |
1.5~30 N-m
1.11~22.12 ft-lb
13.3~265.5 in-lb
15.3~306.1kg-cm |
0.01 N-m
0.01 ft-lb
0.1 in-lb
0.1 kg-cm |
No |
|
CU |
Yes |
|
DP3-060 |
CN |
3/8 |
290 |
60 N-m
44.24 ft-lb
530.9 in-lb
612.2kg-cm |
3~60 N-m
2.21~44.24 ft-lb
265~530.9in-lb
30.6~612.2kg-cm |
0.01 N-m
0.01 ft-lb
0.1 in-lb
0.1 kg-cm |
No |
|
CU |
Yes |
|
DP3-085 |
CN |
3/8 |
290 |
85 N-m
62.7 ft-lb
725 in-lb
867 kg-cm |
4.2~85N-m
3.1~62.7ft-lb
37~725in-lb
43~867kg-cm |
0.1 N-m
0.1 ft-lb
1 in-lb
1 kg-cm |
No |
|
CU |
Yes |
